Drive system Belt-driven (with digital rotation correction)
Drive motor DC servo motor
RPM 33-1/3, 45 or 78 revolutions per minute
S/N (signal-to-noise) ratio Less than 60 dB (DIN-B)
Cartridge model Stereo ceramic cartridge included (MM supported)
Maximum input level AUX IN: 2.5 Vp
Maximum output level
LINE OUT : 2.3 Vp, THD 1%
PHONO OUT: 300 mV (1 kHz, 5cm/sec)
PHONO preamp gain
Standard value: 34.5 dB; equalizer characteristics: RIAA
Digital signal processing
A/D, D/A: 44.1 kHz@16-bit, stereo
Crossfader: 44.1 kHz, 32-bit float, stereo
Mix: 44.1 kHz, 32-bit float, stereo
Looper: 44.1 kHz, 16-bit, stereo; max. recording time: approx. 20 sec
Filter: 44.1 kHz, 32-bit float, stereo; type: OFF, FILTER1, FILTER2, FILTER3
Delay: 44.1 kHz, 32-bit float, stereo; feedback (0%–80%), time (1,000 ms–10 ms)
Power consumption 2.35 W
Power supply AC adapter (included), six AA batteries (alkaline or nickel-metal hydride)
Weight 2.3 kg/5.07 lb
Dimensions 370 x 280 x 84 mm/14.57? x 11.02? x 3.30?; with cover on: 370 x 286 x 87 mm/14.57? x 11.26? x 3.43?
Included items
AC adapter, AC adapter replacement plug (5 types), dust cover, slip mat, EP adapter, Quick Start Guide
