Sound Generation Method Analog Modeling Synthesis System
Synthesizer Program
Multi Timbral 2 (max, Split/Dual Mode)
Voices 4 voices
Sound Source
2 Oscillator + Noise Generator,
Multi Mode Filter(-24dB/octLPF,-12dB/oct LPF/BPF/HPF)
EG×2
LFO×2
Virtual Patch×4
Vocoder Program
Voices 4 voices
Sound Source
1 Oscillator +Noise Generator
EG×1
LFO×2
8 Channels vocoder
Level and pan of each channel can be edited
Formant Shift function
Programs 128 programs
Effects Modulation effects (3 types), Delay (3 types), Equalizer
Arpeggiator 6 types
Controllers Real-Time control knob X 4 (3 level Selection), Arpeggio ON/OFF
Keyboards 37 Keys (mini-keyboard, keyboard has velocity)
Inputs AUDIO IN 1,2, Level switch LINE/MIC, [AUDIO IN 1, 2 (LINE) ], [AUDIO IN 2 (MIC)]
Outputs L/MONO, R, Headphones
MIDI IN, OUT, THRU
Display 3 characters×1 line with 8 segment LED
Power Supply DC 9 V (AC adapter), or six AA alkaline batteries (sold separately)
Power Consumption 6.4 W (MAX)
Dimensions
(W) x (D) x (H) 524 x 232 x 70mm/20.63" x 9.13" x 2.76"
Weight 2.2 kg/4.85 lbs. (without batteries and included microphone)
Accessories AC adapter (DC 9 V, 600 mA), Condenser Microphone
